The JW C741 DDR5 16-Slot Motherboard is a high-performance enterprise server and workstation platform built on the Intel C741 chipset. Designed for dual Intel Xeon Scalable 4th and 5th Generation processors, it supports up to 4TB+ of DDR5 ECC RDIMM memory
OEM

The JW C741 DDR5 16-Slot Motherboard is a high-performance enterprise server and workstation platform built on the Intel C741 chipset. Designed for dual Intel Xeon Scalable 4th and 5th Generation processors, it supports up to 4TB+ of DDR5 ECC RDIMM memory

Supplier: Verified OEM partner New

Category: Motherboards

INR 130,000.00 Starting price (MOQ 1)
  • Min order: 1
  • Supports exchange: Yes
Support

List your business & products here. Become a supplier.

Description

The JW C741 DDR5 16-Slot Motherboard is a high-performance enterprise server and workstation platform built on the Intel C741 chipset. Designed for dual Intel Xeon Scalable 4th and 5th Generation processors, it supports up to 4TB+ of DDR5 ECC RDIMM memory across 16 DIMM slots, delivering exceptional performance for virtualization, AI, machine learning, database management, and scientific computing workloads. With PCIe 5.0 expansion, multi-GPU support, integrated BMC management powered by ASPEED AST2600, IPMI remote administration, and enterprise-class reliability, this motherboard is engineered for demanding data center, cloud infrastructure, and mission-critical workstation deployments.

Full product details

Overview
Product name
  • The JW C741 DDR5 16-Slot Motherboard is a high-performance enterprise server and workstation platform built on the Intel C741 chipset. Designed for dual Intel Xeon Scalable 4th and 5th Generation processors, it supports up to 4TB+ of DDR5 ECC RDIMM memory
CategoryMotherboards
BrandJWIPC (JW)
Enquiry onlyNo
Supports exchangeYes
Pricing & MOQ
Base priceINR 130,000.00
Sample availableNo
Sample priceINR 130,000.00
Min order quantity (MOQ)1
Max order quantity10
Technical Specs
Dimensions330 × 305 mm
WeightApprox. 4.0 – 6.0 kg
Technical specifications
  • PlatformEnterprise Server / Workstation Chipset Intel C741
  • CPU SocketDual LGA4677
  • Supported ProcessorsIntel Xeon Scalable 4th & 5th Gen Processors
  • Form FactorEEB / SSI-EEB
  • Memory TypeDDR5 ECC Registered DIMM (RDIMM)
  • Memory Slots16 × DDR5 DIMM
  • Maximum Memory CapacityUp to 4TB+ (CPU & Module Dependent)
  • Memory Architecture8-Channel per CPU
  • ECC SupportYes
  • BIOSUEFI Server BIOS
  • CPU ConfigurationDual Socket
  • Processor FamilyIntel Xeon Scalable
  • Supported SeriesXeon Silver, Gold, Platinum
  • Maximum CPU Count2
  • Multi-Core SupportUp to 128+ Total Cores (CPU Dependent)
  • Virtualization SupportIntel VT-x & VT-d
  • Memory SpeedDDR5 4800–5600 MT/s
  • ECC ProtectionYes
  • Registered Memory SupportYes
  • Load Reduced DIMM SupportModel Dependent
  • PCIe GenerationPCIe 5.0
  • PCIe x16 SlotsUp to 6–8 PCIe 5.0 Slots
  • GPU SupportMulti-GPU Ready
  • AI Accelerator SupportYes
  • High-Speed Networking CardsSupported
  • Storage Controller CardsSupported
  • M.2 NVMe Slots2 × M.2 NVMe
  • U.2/U.3 SupportAvailable (Model Dependent)
  • SATA PortsUp to 8 × SATA 6Gb/s
  • SlimSAS PortsMultiple
  • RAID SupportRAID 0, 1, 5, 10
  • NVMe RAIDSupported
  • TPM 2.0Supported
  • LANDual 10GbE / Dual 25GbE (Model Dependent)
  • Dedicated Management PortYes
  • BMC ControllerASPEED AST2600
  • IPMI SupportYes
  • Remote KVMYes
  • Server MonitoringHardware-Level Monitoring
  • Enterprise ManagementSupported
Supply, Shipping & Delivery
Production lead time (days)5
Supply ability per month100
Compliance & Customization
Warranty
  • 5 years
OEM / ODM availableNo
Custom logo availableNo
Custom packaging availableNo
Private label supportNo
