ASRock B660M-HDV DDR4 Motherboard Intel B660 LGA1700 Micro-ATX

Supplier: Verified OEM partner New

Category: Motherboards

INR 17,000.00 Starting price (MOQ 1)

Min order: 1
Supports exchange: Yes

Support

List your business & products here. Become a supplier.

Description

The ASRock B660M-HDV DDR4 is a dependable Micro-ATX motherboard built on the Intel B660 chipset for Intel LGA1700 processors. Supporting Intel 12th, 13th, and 14th Generation CPUs, it offers up to 64GB DDR4 memory, PCIe 4.0 graphics support, Hyper M.2 PCIe 4.0 NVMe storage, DisplayPort 1.4, HDMI 2.1, Gigabit LAN, and 7.1-channel HD Audio with Nahimic support. Its compact design and essential features make it an excellent choice for office desktops, educational systems, home PCs, and budget gaming builds.

Full product details

Overview

Product name	ASRock B660M-HDV DDR4 Motherboard Intel B660 LGA1700 Micro-ATX
Category	Motherboards
Brand	ASRock
Model number	B660M-HDV
Enquiry only	No
Supports exchange	Yes

Pricing & MOQ

Base price	INR 17,000.00
Sample available	No
Sample price	INR 17,000.00
Min order quantity (MOQ)	1
Max order quantity	100

Technical Specs

Dimensions	230 × 201 mm
Weight	Approx. 1.1–1.4 kg
Technical specifications CPU SocketLGA1700 Form FactorMicro-ATX Memory TypeDDR4 Memory Slots2 x DDR4 DIMM Maximum Memory Capacity64GB BIOS TypeUEFI AMI BIOS PlatformIntel 12th, 13th & 14th Gen Processors Standard Memory SpeedDDR4 3200MHz Maximum OC SpeedDDR4 5066MHz+ (OC) XMP SupportYes PCIe x16 Slot1 x PCIe 4.0 x16 PCIe x1 Slot1 x PCIe 3.0 x1 Multi-GPU SupportNo Hyper M.2 Slot1 x PCIe 4.0 x4 NVMe SATA Ports4 x SATA III 6Gb/s RAID SupportRAID 0 / 1 / 5 / 10 Intel Optane MemorySupported HDMI Port1 x HDMI 2.1 DisplayPort1 x DisplayPort 1.4 Maximum HDMI Resolution4K @ 60Hz Maximum DP Resolution7680 × 4320 @ 60Hz (8K) Integrated Graphics SupportYes LAN ControllerRealtek Gigabit LAN Ethernet Speed10/100/1000 Mbps Wi-FiNo BluetoothNo
