ASUS PRIME H510M-E Motherboard | Intel H510 LGA1200 Micro-ATX DDR4 Motherboard

Supplier: Verified OEM partner New

Category: Motherboards

INR 6,000.00 Starting price (MOQ 1)

Min order: 1
Supports exchange: Yes

Support

List your business & products here. Become a supplier.

Description

ASUS PRIME H510M-E motherboard with Intel H510 chipset, LGA1200 socket, support for Intel 10th & 11th Gen processors, up to 64GB DDR4 RAM, PCIe 4.0, M.2 NVMe SSD support, Intel Gigabit LAN, and triple display connectivity.

Full product details

Overview

Product name	ASUS PRIME H510M-E Motherboard \| Intel H510 LGA1200 Micro-ATX DDR4 Motherboard
Category	Motherboards
Brand	ASUS
Model number	PRIME H510M-E
Enquiry only	No
Supports exchange	Yes

Pricing & MOQ

Base price	INR 6,000.00
Sample available	No
Sample price	INR 6,000.00
Min order quantity (MOQ)	1
Max order quantity	100

Technical Specs

Dimensions	226 × 211 mm
Weight	Approx. 1.10 – 1.40 kg
Technical specifications ChipsetIntel H510 Express CPU SocketLGA1200 Supported ProcessorsIntel 11th Gen & 10th Gen Core i9/i7/i5/i3, Pentium Gold, Celeron Form FactorMicro-ATX Memory TypeDDR4 Memory Slots2 × DDR4 DIMM Maximum Memory Capacity64GB Memory SpeedDDR4 3200 (OC) / 2933 / 2666 / 2400 / 2133 MHz Memory ArchitectureDual Channel BIOS128Mb UEFI AMI BIOS LANIntel I219-V Gigabit Ethernet AudioRealtek ALC897/887 7.1 HD Audio XMP SupportYes ECC SupportNon-ECC Unbuffered Supported Memory SpeedUp to DDR4-3200 (CPU dependent) PCIe x16 Slot1 × PCIe 4.0/3.0 x16 PCIe x1 Slots2 × PCIe 3.0 x1 M.2 Slot1 × M.2 (2242/2260/2280) PCIe 3.0 x4 / SATA SATA Ports4 × SATA 6Gb/s RGB Header1 × RGB Header TPM HeaderSPI TPM Header COM Port HeaderYes DisplayPort 1.41 HDMI1 VGA (D-Sub)1 USB 3.2 Gen1 Type-A2 USB 2.02 Intel Gigabit LAN1 Audio Jacks3 PS/2 Keyboard Port1 PS/2 Mouse Port1 24-Pin ATX Power1 8-Pin CPU Power1 CPU Fan Header1 Chassis Fan Header1 USB 3.2 Gen1 Header1 USB 2.0 Headers2 Front Audio Header1 S/PDIF Out Header1 System Panel Header1
